LARGE DIAMETER, BRAID/COIL REINFORCED SHAFTS

AT A GLANCE

• Large diameter shafts (up to 42F) with dimensional stability
• Ultra-thin walls
• Large portfolio of braid/coil configurations and materials
• Custom-engineer the stiffness of the tip and shaft segments to match the application

Custom-Configured, Reinforced Shafts Up to 42F

• Obtain large shaft diameters (up to 42F) while maintaining dimensional stability.
• Ultra-thin walls – industry leading capabilities and tolerances
• Braids with optional longitudinal wire reinforcement increase stability and pushability.
• Substrate/liner options achieve lubricity, clarity, and cost considerations.
• Custom-configure the stiffness of the tip and shaft segments to match your application.
• Braid configurations and materials available for flexibility, stability, and/or pushability.

Applications:

• Introducers
• Endoscopy
• Applications requiring a large diameter sheath with thin walls.

Shaft Materials:

• Liner/Substrate materials: FEP, EFEP, HDPE, PEBA, or customer specified.
• Jacket materials: PEBA Polyamide, PUR, or customer specified.
• Braid materials: Round or flat stainless steel wire.

Radiopacity Options:

• Encapsulated or embedded marker bands.
• Encapsulated tungsten (W) tri-layer or atraumatic tip.
• High loading of conventional radiopaque fillers:
  • Barium Sulfate
  • Bismuth Trioxide
  • Bismuth Subcarbonate

Finishing Operations:

• Flaring.
• Hub options: Insert molding or custom hubs.
• Braid materials: Round or flat stainless steel wire.

Configurations:

• Coiled, reinforced tubing.
• Braided: proximal; coiled: distal.
• Tip attachment.
• Atraumatic radiopaque tip.
• Tip geometry custom-configured to your application.

Sterilization:

• Gamma
• E-beam
• EtO

Shaft Guide

“Large Diameter, Braid/Coil Reinforced Shafts” brochure, read online or download a PDF

Customization Is What We Are All About

Teleflex Medical OEM is your single source solution for product development and manufacturing. Our extensive, vertically integrated capabilities include design for manufacture, engineering, regulatory affairs, material selection and formulation, prototyping, testing and validation, manufacturing, finishing operations, assembly, and packaging.
READ MORE
